How to create the Value Stream Design?

The Value Stream Method gives you pre-defined symbols that helps you to create your Value Stream

Use the data box to fill in all relevant process information, e. g. takt time

Make sure to include all interactions between two process steps, including additional storage or handling steps

In cases information is stored on stock or double handled, make sure to put that information on the sheet

Use pre-defined symbols like for Kanban calls, searching material or stocks.

Ein gesamtes VSD einf├╝gen als Beispiel (mit den LA-Symboliken!)
